Q#1 Transducers GATE EE 1997 (Set 1) MCQ +1 mark -0.33 marks

In a LVDT, the two secondary voltages

Are independent of the core position

Vary unequally depending on the core position

Vary equally depending on the core position

Are always in the phase quadrature

Explanation Locked!

Unlock this branch to view the explanation, track, bookmark and more.

Sign in to Unlock
Q#2 Transducers GATE EE 1995 (Set 1) MCQ +1 mark -0.33 marks

Fringing in a capacitance type transducer can be minimized by providing a

Shunt resistor

Grounding wire

Guard ring

Dielectric coating

Explanation Locked!

Unlock this branch to view the explanation, track, bookmark and more.

Sign in to Unlock
Q#3 Transducers GATE EE 1994 (Set 1) NAT +1 mark -0 marks

A piezo-electric pick up is an example for an active transducer. (True=1/False=0)

Explanation Locked!

Unlock this branch to view the explanation, track, bookmark and more.

Sign in to Unlock
Q#4 Transducers GATE EE 1993 (Set 1) MCQ +1 mark -0.33 marks

A metal strain gauge has factor of two. Its nominal resistance is 120 ohms. If it undergoes a strain of, the value of change of resistance in response to the strain is

240 ohms

Explanation Locked!

Unlock this branch to view the explanation, track, bookmark and more.

Sign in to Unlock
